Inicio > Productos> Módulo de la luz de calle del LED> Módulo TYPE2-M de la lente de 192PCS SMD3030 1W 6V LED 48 puntos de la lente 150LM/W

Módulo TYPE2-M de la lente de 192PCS SMD3030 1W 6V LED 48 puntos de la lente 150LM/W

192PCS SMD3030 1W 6V LED Lens Module TYPE2-M 48 Points Lens 150LM/W

Informacion basica

Lugar de origen:	Shenzhen, China
Nombre de la marca:	Sunshineopto
Certificación:	SGS,ROHS
Número de modelo:	SUN-LD240X160-48X4-T2-M

Cantidad de orden mínima:	1
Detalles de empaquetado:	Cartones
Tiempo de entrega:	3-4 días laborables
Condiciones de pago:	T/T, PAYPAL, Western Union, gramo del dinero
Capacidad de la fuente:	5000pcs/months

Mejor precio Contactar ahora

Información detallada

Nombre de producto:	módulo TYPE2-M de 100W 150W 192PCS 3030 SMD 1W 6V LED 48 puntos de la lente	Modelo NO.:	SUN-LD240X160-48X4-T2-M
Ángulo de haz:	TYPE2-M	Tamaño de la LENTE:	240X160M M
Material:	PC óptica del grado	MICROPROCESADOR DEL LED:	3030 SMD LED, 150mA, 6V, 140-150LM/W
Tranmittance:	el 91%	uso:	Alta luz de la bahía/luz de calle/luz del área/luz del proyecto/luz del cuadrado y así sucesivamente
Tamaño del PWB:	216x136x1.5m m	Circuito para el tablero del PWB:	8 series 24parallel, 48V HICIERON SALIR
Resaltar:	Módulo de la lente de SMD3030 LED , módulo de la lente de 1W 6V LED , Lente llevada poder más elevado 150LM/W

Descripción de producto

100W 150W 192PCS 3030 SMD 1W 6V LED module TYPE2-M 48 points lens

Features :

This SKD 192 pieces 3030smd 1w LED Array lens with PCB Module is best choice to design power lamps like 100-150w and so on .
It’s the lowest total cost solution ,they can replace existing Metal Halide or HPS bulbs, the old housings can be re-used. The total cost is significantly reduced compared with using new complete LED fixtures.
Industry-leading thermal management utilizing technology
Operating temperature range: from 35 Celsius degree to 70 Celsius degree.
The LED retrofit kits contain no any mercury or lead.
Does not produce UV rays that harm people’s eyes.
Directional light means no light pollution, dark sky compliance.
Optic lenses are available for projects that need smaller beam angles, like 80X150/ 90/60/90X120 degree and Vertrial 80x150 degree and so on.

Specifications:

1, Product Name	100W 150W 192PCS 3030 SMD 1W 6V LED module TYPE2-M 48 points lens
2, Model No	SUN-LD240X160-48X4-T2-M
3, Main parts	48 Array lens , silicon gasket+PCB+ 3030 SMD LED
4, Lens Material	PC
5, Lens size	240X160MM
6, Transmittance	91%
7,LEDS	Orginal package 3030SMD LED, 140-150LM/W, 150mA,6v
8, Sample	3-4 work day
9, Delivery	5-7 work days for 10000 sets
10, Angle	Typ2-M
11, Quality guarantee	If you receive defective items, please email us a picture of the defective part. We will send you replacement without extra charger, or offer refund.
12, Main market	Europe, South America,North America, Asia

Shipping and delivery time:

DHL/UPS/TNT/FEDEX	4-5 working days
EMS	10-15 working days
HK Post Air Mail Register	15-18 working days
Trade Terms	FOB\|EXW\|CIF\|CFR
Sample availability	YES
Delivery time	3-4 working days

Applications:
It is used in the street light ,high way led lamp,tunnel lamp ,square lamp,road lamp, city lighting, parking spot lamp, track lighting fixtures ,scenery area ,retail lighting and other applications where high luminous flux is desired.
Módulo TYPE2-M de la lente de 192PCS SMD3030 1W 6V LED 48 puntos de la lente 150LM/W 0

LENS Dimensions :

Beam pattern:

TYPE2-M:
